140LPW 300W UFO LED High Bay Light IP65 strong Housing
Options: > Driver: Meanwell HBG(Round),ELG/HLG(Retangle),Sosen;
> Controls and Dimming: 1-10V, DALI, Motion sensor,Daylight sensor,Zigbee and Emergency;
> Reflector : PC reflector / Al reflector;
> Lens : 60°/90° (with Pearl or Stripe Lens)/120° (without PC or Toughened Glass Cover) /140° (with Grille
Stripe PC Cover);
> Installation: Loop Hanging, Ceiling Mounting, Wall Mounting;
> Factories / Warehouses / Supermarket
> Exhibitions / Showrooms / Animal Farm
> Barns and Riding Halls / Logistic Center
> High Rooms and Halls / Stadium / Chemical Plant
> Traditional lamp replacement
| Model No. | DR-HB100-EGXP | DR-HB150-EGXP | DR-HB200-EGXP | DR-HB240-EGXP | DR-HB300-EGXP |
| System Watts/W | 100W | 150W | 200W | 240W | 300W |
| System Efficiency/LPW | 140LPW |
| Lumen Output/lm | 14.000±5% | 21.000±5% | 28.000±5% | 33.600±5% | 42.000±5% |
| Rated Input Voltage/V | AC200~240V, 50/60Hz /(AC100~277V, 50/60Hz Optional) |
| LEDs Light Source | SMD3030 |
| SDCM | <5 |
| CCT/K | 5000K for Standard (3000K/4000K/5700K/6500K Optional) |
| CRI/Ra | >70Ra (>80Ra for Option) |
| Power Factor | >0.95 |
| THD | <10% |
| Beam Angle(Optional) | 60°/90°/120°/140° |
| UGR | <25 |
| Surge Protection | 3.75~4KV SPD built in Driver,Exterior SPD 20KV Meanwell Optional |
| LED Driver | Meanwell HBG/ELG/HLG,Sosen |
| IP Rating | IP65 |
| Dimming(Optional) | 0/1-10V/DALI/Zigbee |
| Sensor(Optional) | Motion Sensor,Daylight Sensor |
| Emergency(Optional) | Available (30W @ 3Hrs for Standard) |
| Protection Class | ClassⅠ |
| Finishing Color(Optional) | Black RAL9017(Standard) / White RAL9016 Optional |
| Material | Aluminum+PC (Toughened Glass Cover Optional) |
| Lifespan/hrs | 70.000 Hrs (Ta=30℃@L70) |
| Operation Temp/℃ | 40°C to + 50°C(-40°F to 122°F) |
| Storage Temp/℃ | - 40°C to + 65°C(-40°F to 149°F) |
| Installation(Optional) | Loop Hanging, Ceiling Mounting, Wall Mounting |
| Certificate | CE(EMC+LVD),RoHS,ENEC ,D-Mark,SAA,RCM Available |
| Character/Power | 100W | 150W | 200W | 240W | 300W | |
| A / mm | Ø280 | Ø338 | Ø400 | Ø400 | Ø440 |
| B / mm | 164 | 182 | 164 | 172 | 182 |
DALI Device
DALI Intelligent Control Diagram
DALI Intelligent Control Operator Interface
| Model No. | Net Weight/Kg | Outer Carton Size/mm | Gross Weight/Kg | QTY”/CTN |
| DR-HB100-EGXP | 4.2 | 355*350*165 | 4.9 | 1PCS/CTN |
| DR-HB150-EGXP | 4.6 | 415*410*175 | 5.4 | 1PCS/CTN |
| DR-HB200-EGXP | 4.8 | 475*470*195 | 5.6 | 1PCS/CTN |
| DR-HB240-EGXP | 6.9 | 475*470*195 | 7.8 | 1PCS/CTN |
| DR-HB300-EGXP | 7.5 | 500*495*195 | 8.8 | 1PCS/CTN |
FAQ
Q1:LED high bay lights have the following outstanding features:.
RE:1, Environmental protection, energy saving, the normal life of the lamp is more than 30,000 hours.
2, Under the front embankment of equal brightness, 70W LED high bay lights can save 60% electricity than 175W high pressure sodium lights.
3. In the industrial and mining light source part, the LED industrial and mining lamp manufacturer uses American company chips as the light source, which has high efficiency, low light decay, large current margin, and the rated current of the chip is 700mA. In practice, only 310mA is used. Good heat dissipation plan, solid crystal uses solder The solder has low thermal resistance, and the operating temperature of the chip is low. The actual junction temperature is less than or equal to 50°C, which ensures the stability and longevity of the operation.
